Cells Li-Ion EVE INR21700-50E 5000mAh 15A
Cells Li-Ion EVE INR21700-50E 5000mAh 15A
Lithium-ion cells EVE INR21700-50E 5000mAh
Efficient lithium-ion cell EVE INR21700-50E, with a capacity of 5000mAh, a maximum discharge current of 15A, and a recommended load of 9A in a battery pack, is an excellent solution for applications such as e-bikes, electric scooters, and portable devices. Its high capacity and stable current performance make it ideal for building reliable and durable battery packs.
Cell Voltage
Maximum Charging Voltage: 4.20V
Cell Capacity
Nominal Capacity: 5 Ah
EVE INR21700-50E 5000mAh
Lithium-ion cells by EVE
Informatio
Factory-new cells.
The option to charge and balance cells before shipment is available.
Cell Balancing Service - Click here
Documentation
Datasheet - Click here
Cell capacity test EVE INR21700-50E 5000mAh
Brand
Warranty
E-cigarettes
No
Power tools
No
Maximum working temperature
50st
Maximum charging voltage
4,20V
Maximum discharge current
15A
Maximum discharge current in batteryMore
The discharge current when working in packs (a battery composed of many 18650 or 21700 cells) is lower than the current specified in the catalog note for one cell. This is due to the fact that many cells in the pack heat up from each other. The increased and uneven temperature of the pack causes rapid degradation of the cell and such a battery may not survive even one season. For the safety and long life of your battery, always design it safely based on the maximum operating current in the pack. Do not overload the cells, do not build a pack based on the maximum current for 1 cell - otherwise your pack will have a very short lifespan.
9A
Maximum charging current
5A
Rated voltage
3,6V
Pojemność minimalna
4900mAh
Rated capacity
5000mAh
Internal resistance
17 mΩ
State
New
Standard charging current
1A
Technology
Li-ion
Cells type
21700
Wysokoprądowe
Nie
Gwarancja na Ogniwa nowe 2 lata
Gwarancja na Ogniwa nowe 2 lata
